Specification
Bore size(mm) | 10 | 16 | 20 | 25 | 32 |
Action | Double acting type | ||||
Fluid | Air(filtered through 40µ filter element) | ||||
Operating pressure | 0.1~0.9Mpa(1~9kgf/cm²) | ||||
Proof pressure | 1.35Mpa(13.5kgf/cm²) | ||||
Ambient & fluid temperature | -5~70°C | ||||
Cushion type | Fixed bumper | ||||
Port size | M5x0.8 | G1/8 | |||
Body material | Aluminum ally |
